64 Ports FXS VoIP Gateway

The FXS VoIP Gateway offering seamless connectivity between IP-based telephony networks and legacy telephones (POTS), fax machines and PBX systems. The device offers 64 FXS ports, fax over IP and dial plans.

• Cost effective gateway with 64 FXS ports
• Fax over IP (T.38 and Pass-Through)
• Support IPv4 and IPv6
• TR069 and SNMP
• Multiple codecs: G.711A,G.711u,G.723,G.729,AMR_NB,AMR_WB.
• Fully compatible with leading IMS/NGN, SIP based IP telephony system

Product Details



Voice Features

•    Analog User: 64*FXS

•    Codec: 711A, G.711u, G.723, G.729, AMR_NB, AMR_WB

•    Protocol: TCP, UDP or TLS

•    FAX: Transparent, T38, VBD

•    Voice Functions:

Call Forward on Busy

Call Forward on No Answer

Call Forward Unconditional

•    Caller ID

•    Caller ID on Call Waiting

•    Call Waiting

•    Three-way Calling

•    Ring groups



Firewall & Security

•    Firewall: IDS&IPS, Block Ping/ICMP/IDENT, SPI Firewall, Ports can restriction

•    Access control: Blocking by URL, IP Address, Mac Address, Protocol Type, Port



Data Network

•    WAN: 1×10/100Mbps Ethernet

•    LAN: 1x10/100Mbps Ethernet

•    WAN: Static IP, PPPoE, DHCP

•    NAT: ALG, DMZ, PAT



Management

•    Protocol: Telnet, TR069, Web

•    LED Indications: 10 LED indicators for PWR, REG, ALM, RUN and User lines

•    Control Button: Reset Button



Environmental

•    Size: 483×239×44mm

•    Net Weight: <2Kg

•    Power Supply: AC 220V

•    Operation: 0° to 40°C

•    Humidity: 10-90% non-condensing
