Stronger Performance, More Possibilities

Equipped with powerful chipset, Y10 series has great performance, which is capable of extend more services for different business demands.

Superior HD Audio, Better Communication

With leading Smart Noise Filtering Technology, which delivers excellent sound quality without extraneous noises and allows fluent conversations.

Classic Design, Practical Details

Y10 has friendly operation interface, provides users with more comfortable and ideal operation experience.

All-in-one Management Platform

Supports EMS system, which is easy to manage, upgrade and configure IP Phones, help users to save maintenance costs.

Product Details

Key Features

•    HD Voice

•    Graphical LCD with backlight

•    128*64 Pixels

•    Two-port 10/100M Ethernet Switch

•    Support Opus codec

•    1 SIP account

•    Local 5-way conferencing

•    Stand with 2 adjustable angles

•    PoE optional

•    Wall Mountable

Product Features

Audio Feature

•    Voice:  handset, speaker, headset

•    Smart Noise Filtering

•    Wideband codec: Opus, G.722

•    Narrowband codec: G.711(A/μ), G.729, G.729A, iLBC

•    DTMF: RFC 2833,SIP INFO, Inband

•    Full-duplex hands-free speakerphone with AEC

•    VAD, CNG, AEC, PLC, AJB, AGC

Display & Indicator

•    128*64 -pixel graphical LCD with backlight

•    LED for call and message waiting indication

•    Illuminated LED for line status information

•    Intuitive user interface with icons and soft keys

•    Multilingual user interface

•    Caller ID with name and number

Phone Feature

•    1 SIP accounts

•    Call hold, DND, Speed dial

•    Call forward, call waiting, call transfer

•    Redial, call return, auto answer

•    Local 5-way conferencing

•    Direct IP call, Time/Date Management

Function Keys

•    3 features keys: HandFree, headset, redial,

•    2 navigation keys

•    Volume control keys

Directory

•    Local phonebook up to 1000 entries

•    Blacklist

•    XML/LDAP remote phonebook

•    Smart dialing

•    Phonebook search/import/export

•    Call history: dialed/received/missed

IP-PBX Features

•    BLF, Anonymous call

•    Anonymous call rejection

•    Call Park, call pickup

Network Security

•    SIP v1(RF2543), v2(RFC3261)

•    NAT traversal: STUN

•    Proxy and peer-to-peer SIP

•    IP assignment: static/DHCP

•    HTTP/HTTPS web server

•    SNTP

•    UDP/TCP/DNS-SRV (RFC 3263)

•    SRTP/ SIP TLS

•    HTTPS certificate manager

•    IPv6

•    DHCP VLAN/LLDP

Management

•    Configure via browser/phone/auto-provision

•    Auto provision via FTP/TFTP/HTTP/HTTPS

•    TR-069, System log

•    Reset to factory, reboot

Other Physical Features

•    2 * RJ-45 10/100Mbps

•    1 * RJ9 (4P4C) Handset

•    1 * RJ9 (4P4C) Headset

•    Power Adapter (Optional)

•    100-240VAC Input, DC 5V/1A Output

•    Power Consumption:2~3W

•    Dimension(W*D*H*T):

•    190mm*153mm*162mm*42mm

•    Operating humidity: 10~95%

•    Operating temperature: -10~50°C
