• Enjoy high-quality audio streaming with minimal delay using our integrated IP decoder. This module supports real-time playback of network music streams with under 30ms of latency.
• The system is fully compatible with the SIP (RFC3261) protocol for seamless integration.
• Advanced energy-saving and noise reduction technologies provide immersive sound without disturbance.
• At the core is a 5-inch coaxial driver, delivering CD-level quality through the integrated 20W HD amplifier. Crisp highs and deep lows come together for beautiful, balanced audio.
• Stream your favorite playlists or internet radio stations with the convenience of network connectivity and the performance of our specialized decoding hardware. Low latency playback and high efficiency design provide an unparalleled listening experience.

Product Details

Basic Parameters

•    2 SIP lines, SIP v2.0

•    Output: 20W

•    Volume adjustment remotely

•    Action URL / Active URI

•    Offline ringing module (Optional)

Product Features

Audio Parameters

•    Codes: G.711a/u, G.723.1, G.726-32K, G.729AB, G.722

•    AEC, DTMF (In-band) & DTMF(RFC2833)/ SIP info

•    Frequency range: 20Hz-20KHz (≤±3dB)

•    Signal-to-noise ratio: ≥75dB

•    Harmonic Distortion：≤1%

Network

•    IPv4

•    DHCP / Static / PPPoE

•    LAN connection: RJ45 10/100Mbps

•    Protocol: SIP(RFC3261), HTTP/HTTPS, SNTP, NTP, RTSP, TCP, UDP, DHCP

•    Support QoS: 802.1p / q, DSCP；Web Filter

•    Support Primary and secondary DNS servers

•    Support VLAN，SNTP client；VPN L2TP/PPTP/IPSec

Management

•    Via FTP/TFTP DHCP OPT66 / SIP/HTTP/HTTPS/PNP/TR069 automatically

•    Web management interface

•    Web Packet capture (Web -based Packet - dump)

•    Configuration export/import

•    Software upgrade

•    System logs (Syslog)

Other  specifications

•    Dimensions (h/w/d): Ф200*100(d) mm

•    Weight: 1.6kg

•    Working temperature: 5~45℃

•    Working Humidity：20%~80%

•    Color: White

•    Grille: Surface-treated metal mesh plate

•    Speaker shell: ABS

•    Installation dimensions：Ф172mm

•    Power Supply: 24V/2A
